ABH-MS2 MANUAL

ABH-MS2 (micro base station)



Outdoor Wireless Device



ABH-MS2 (micro base station)

Outdoor Wireless Device







The ABH-MS2 is a point-to-point or point-to-multipoint wireless integrated device that utilizes 2 x 2 MIMO technology to deliver up to 300Mbps (110Mbps full duplex) TCP throughput and high packet forwarding performance.​

The product features a series of advanced software systems that provide optimal point-to-point long-distance connections with high throughput. The company adopts a proprietary dynamic TDD technology system that can dynamically allocate bandwidth as needed, thereby effectively improving connection efficiency and reducing the impact of distance on throughput.

ABH-MS2 point-to-point products also feature automatic repeat request (ARQ) technology, which provides a powerful software error correction system for optimizing data communications, and can still provide high throughput, high bandwidth and long-distance transmission even in the presence of interference. distance connection.

This product is also compatible with online link calculators and remote control management systems, provides operation diagnosis and configuration management functions, and realizes functions such as centralized configuration and statistical services.

ABH-MS2 provides broadband service operators with a cost-effective point-to-point transmission solution. It works in the ISM 5GHz license-free frequency band and uses the BHU private bridge protocol with high security. Using MIMO, OFDM and airX (spatially adaptive optimal communication) technology, it supports data transmission rates up to 100 Mbps and has strong anti-interference capabilities. It has excellent radio frequency performance, with a receiving sensitivity of up to -95dBm, an output power of up to 27dBm, and a built-in 16dBi high-gain directional antenna. Supports long-distance transmission and has the robustness of carrier-grade products. It is small in size, light in weight, easy to install, and has bridge link debugging functions, which can effectively help users solve difficult debugging problems in wireless network installation. Provides a friendly configuration interface, making configuration and maintenance simple and convenient.

Product Parameters

Hardware Product Specifications
Product Model ABH-MS2
processing unit Atheros AR9341
random access memory (RAM) 64MB
Flash 8MB
operating frequency 2.412~2.484GHz
Maximum Transmit Power 27dBm (500mv)
power adjustment Supports automatic/manual configuration
receiver sensitivity Up to -100dBm
modulation technology 802.11b/ BPSK/ QPSK/CCK/802:11g/n:BPSK,QPSK,16-QAM,64-QAM
data rate 11b: 1,2,5.5,11Mbps/11g: 6,9,12,18,24,36, 48,54Mbps

11n: MCS0~MCS15/20MHz: 144.4Mbps/40MHz: 300Mbps

connection with high-ranking officials Built-in directional dual polarization Antenna gain: 12dBi

Horizontal beam: 65° Vertical beam: 30&deg.

indicator light 1 power indicator 3 signal strength indicators

1 network port status indicator 1 status indicator

Ethernet port 2 10/100Mbps Adaptive
reset button 1
Power supply method PoE 24V
Power Consumption ≤8W
weights 0.37Kg
sizes 265mmx89mmx61mm
Working temperature and humidity Temperature -40°C to +65°C Temperature 0 to 100%
RF certification FCC Part 15, EN 300 328, EN 301 893, China Ministry of Information Industry Wireless Equipment Type Approval
Software Product Specifications
wireless standard 802.11b/g/n
Virtual AP 4
operating mode Bridge Mode, Route Mode, AP Mode, Trunk Mode, Terminal Mode
Second and third floor functions Supports static IP address, DHCP Client/Server, routing protocols, VLAN and NTP
wireless function Support perimeter station detection/channel scanning/automatic channel selection
security policy Encryption: Supports 64, 128-bit WEP encryption, WPA, WPA2 and WAPI.
Authentication: Support 802.1x authentication, MAC address authentication, PSK authentication, Portal, WAPI, etc.
Supports BSSID binding; anti-DOS attack; SSID hiding; MAC address filtering; Layer 2 forwarding suppression on APs; and virtual APs (multiple SSIDs).
OOS Supports WMM; supports traffic limiting
network protection Support firewall; support speed limit; support anti-question control
system service Support DMZ/UPnP/VPN
WDS be in favor of
unicast and multicast interchange be in favor of
